We implement a parallel branch-and-bound solver for the Travelling Salesman Problem (TSP) using tf::TaskGroup for recursive task parallelism. This example demonstrates how a combinatorial search algorithm with a dynamically growing task tree maps naturally onto Taskflow's cooperative task group model.

What is the Travelling Salesman Problem?

The Travelling Salesman Problem asks: given a set of cities and the distance between every pair of cities, what is the shortest route that visits every city exactly once and returns to the starting city?

It is one of the most studied problems in computer science and operations research. Despite its simple statement, TSP is NP-hard: no known algorithm solves it in polynomial time for arbitrary inputs. The only way to guarantee an optimal solution is exhaustive search, which explores all possible tours. For N cities there are (N-1)!/2 distinct tours, which grows astronomically: 10 cities have 181,440 tours, 15 cities have over 43 billion.

This is precisely why parallelism matters. Each branch of the search tree is independent of every other branch and can be explored on a separate CPU core simultaneously. Branch and bound makes the search tractable by pruning branches that cannot possibly improve the best solution found so far, but the remaining work is still substantial and benefits greatly from parallel execution.

Concrete Walkthrough

Consider four cities A, B, C, D with the following symmetric distance matrix:

      A    B    C    D
A  [  0   10   15   20 ]
B  [ 10    0   35   25 ]
C  [ 15   35    0   30 ]
D  [ 20   25   30    0 ]

Starting from city A, the algorithm builds partial tours by choosing which city to visit next at each step. At each node it computes a lower bound on the best possible completion of the current partial tour. If the lower bound is greater than or equal to the best complete tour found so far, the entire subtree rooted at that node is pruned — there is no point exploring it further. The lower bound used here is:

lb = cost_so_far
   + min outgoing edge from current city to any unvisited city
   + sum of min outgoing edge from each remaining unvisited city

This is a valid lower bound because any completion of the tour must include at least one edge out of the current city and at least one edge incident to each unvisited city. The figure below shows the full search tree for this 4-city instance. Peach nodes are explored, red nodes are pruned (their lower bound already exceeds the best known cost), and the green node is the optimal tour:

The algorithm finds A->B->C->D->A with cost 95 first, then improves to A->B->D->C->A with cost 80 (the optimum). With best_cost equal to 80 established, all four remaining branches are pruned because their lower bounds of 80 or 95 cannot improve on 80. Only 5 of the 9 possible interior nodes are actually evaluated.

Implementation

We represent the distance matrix as a flat vector and implement the branch-and-bound search as a recursive function. Each recursive call creates a tf::TaskGroup to spawn one async task per unvisited city (the "include this city next" branch) while computing one branch directly on the current worker. After spawning, tg.corun() cooperatively waits for all spawned branches to complete without blocking the worker thread.

A global std::atomic<int> tracks the best tour cost found so far. Any branch whose lower bound is at or above this value is pruned immediately by returning without spawning children. When a better complete tour is found, the atomic is updated with compare_exchange_weak so that all workers immediately see the tighter bound on their next pruning check.

#include <taskflow/taskflow.hpp>

tf::Executor executor;
const int INF = std::numeric_limits<int>::max();
std::atomic<int> best_cost{INF};

// ── distance matrix (4 cities: A=0, B=1, C=2, D=3) ───────────────────────
const int N = 4;
const int dist[N][N] = {
  {  0, 10, 15, 20 },
  { 10,  0, 35, 25 },
  { 15, 35,  0, 30 },
  { 20, 25, 30,  0 },
};

// ── lower bound ──────────────────────────────────────────────────────────────
//
// The key insight: any valid completion of the partial tour must include
// at least one edge leaving the current city (to reach the next unvisited
// city) and at least one edge touching each remaining unvisited city
// (to enter or leave it).
//
// We do not know which edges those will be, but we know they cannot be
// shorter than the cheapest available option for each city.
// So the cheapest possible completion is at minimum:
//
//   (1) the shortest edge from the current city to any unvisited city
//   (2) for each unvisited city, its shortest outgoing edge to any other city
//
// Adding these minimum costs to the cost already spent gives a floor: the
// final tour cannot possibly cost less than this bound, regardless of how
// the remaining cities are visited.
// If this floor already meets or exceeds the best complete tour found so
// far, the entire subtree can be pruned safely.
//
// Example: at partial tour A->C (cost=15) with best_cost=80:
//   (1) min edge from C to unvisited {B,D}: min(35,30) = 30
//   (2) min edge from B to anywhere:        min(10,35,25) = 10
//       min edge from D to anywhere:        min(20,25,30) = 20
//   lb = 15 + 30 + 10 + 20 = 75  <  80  =>  not pruned yet
//
// Later at A->C->B (cost=50):
//   (1) min edge from B to unvisited {D}: 25
//   (2) min edge from D to anywhere:      20
//   lb = 50 + 25 + 20 = 95  >=  80  =>  PRUNED
//
int lower_bound(int current, const std::vector<bool>& visited, int cost_so_far) {
  int bound = cost_so_far;

  // (1) cheapest edge we can take out of the current city
  // to reach any city we have not yet visited
  int min_curr = INF;
  for(int v = 0; v < N; v++) {
    if(!visited[v]) min_curr = std::min(min_curr, dist[current][v]);
  }
  if(min_curr == INF) return bound;   // no unvisited cities: tour is complete
  bound += min_curr;

  // (2) for each unvisited city, add the cost of its cheapest outgoing edge
  // to any other city (visited or not, as long as it is not the city itself).
  // This accounts for the fact that we must enter or leave each unvisited city
  // at some point, and the cheapest way to do so is via its minimum edge.
  for(int u = 0; u < N; u++) {
    if(visited[u]) continue;
    int min_u = INF;
    for(int v = 0; v < N; v++) {
      if(v != u) min_u = std::min(min_u, dist[u][v]);
    }
    bound += min_u;
  }
  return bound;
}

void branch_and_bound(
  int current,
  std::vector<bool> visited,
  int cost_so_far,
  int depth
) {
  // compute a lower bound on the best possible tour through this node.
  // if the bound already meets or exceeds the best complete tour found so
  // far by any worker, this entire subtree cannot improve on the best known
  // solution and can be safely discarded.
  int lb = lower_bound(current, visited, cost_so_far);
  if(lb >= best_cost.load(std::memory_order_relaxed)) return;

  // all N cities have been visited: close the tour by returning to city 0.
  // try to update best_cost if this tour is cheaper than any found so far.
  // compare_exchange_weak retries if another worker concurrently updates
  // best_cost, ensuring only the true minimum is stored.
  if(depth == N) {
    int total = cost_so_far + dist[current][0];
    int cur = best_cost.load(std::memory_order_relaxed);
    while(total < cur &&
          !best_cost.compare_exchange_weak(cur, total,
                                          std::memory_order_relaxed,
                                          std::memory_order_relaxed));
    return;
  }

  // create a task group for parallel branching.
  // task_group() is valid here because this function always runs inside a
  // worker thread of the executor (either the root executor.async task or
  // a tg.silent_async task spawned by a parent call).
  auto tg = executor.task_group();

  bool first = true;
  for(int v = 0; v < N; v++) {
    if(visited[v]) continue;

    // prepare the state for the branch where we visit city v next
    std::vector<bool> new_visited = visited;
    new_visited[v] = true;
    int new_cost = cost_so_far + dist[current][v];

    if(first) {
      // run the first unvisited branch directly on the current worker.
      // this avoids task creation overhead for at least one branch per node
      // and keeps the current worker busy without yielding to the scheduler.
      first = false;
      branch_and_bound(v, new_visited, new_cost, depth + 1);
    }
    else {
      // spawn the remaining branches as independent async tasks in the group.
      // each task explores a different city as the next stop in the tour.
      // all spawned tasks share the same best_cost atomic, so a good solution
      // found in any branch immediately tightens the pruning bound for all others.
      tg.silent_async([=]() {
        branch_and_bound(v, new_visited, new_cost, depth + 1);
      });
    }
  }

  // cooperatively wait for all spawned branches to finish.
  // corun() does not block the worker thread: it re-enters the executor's
  // work-stealing loop, executing other pending tasks while waiting.
  // this prevents worker starvation and avoids deadlock in deep recursion.
  tg.corun();
}

int main() {

  std::vector<bool> visited(N, false);
  visited[0] = true;   // start from city A (index 0)

  // the root call must run inside a worker so that task_group() is valid
  executor.async([&]() {
    branch_and_bound(0, visited, 0, 1);
  }).get();

  const char* names[] = {"A", "B", "C", "D"};
  printf("Optimal tour cost: %d\n", best_cost.load());

  return 0;
}

The program output is:

Optimal tour cost: 80

which corresponds to the tour A->B->D->C->A.

Design Points

There are a few important design points worth noting for this example, which also apply generally to parallel search algorithms:

TaskGroup per recursive call: Each invocation of branch_and_bound creates its own tg via executor.task_group(). This is valid because every invocation runs inside a worker thread of the executor — either as the root executor.async task or as a tg.silent_async task spawned by a parent invocation. Attempting to call executor.task_group() from outside a worker thread throws an exception.
First branch on the current worker: Rather than spawning all branches as async tasks, the first unvisited city is explored directly on the current worker. This avoids task creation overhead for at least one branch per node and keeps the worker busy without yielding back to the scheduler. The remaining branches are spawned via tg.silent_async.
Atomic best_cost for pruning: All workers share a single std::atomic<int> best_cost. When any worker finds a better complete tour, it updates best_cost with compare_exchange_weak so that all other workers immediately see the tighter bound on their next pruning check. This is the key mechanism that makes parallel branch and bound more efficient than running independent serial searches: workers continuously share information about the best solution found so far, tightening the pruning bound for the entire parallel search.
Cooperative execution via corun: tg.corun() does not block the calling worker thread. Instead, the worker participates in the executor's work-stealing loop, executing other tasks while waiting for its spawned branches to complete. This prevents worker starvation when the search tree is deep and avoids the deadlock that would result from a blocking wait inside an executor worker.

Note: For larger instances, the visited vector copy on each recursive call becomes a bottleneck. A bitmask (uint32_t or uint64_t) is more efficient for up to 32 or 64 cities respectively. For production TSP solvers, more sophisticated bounding functions such as the Held-Karp lower bound or minimum spanning tree bound deliver much tighter pruning and dramatically reduce the search tree size.
